Wagner by Diversitech WG840459
  1. pin-int

Wagner by Diversitech WG840459

Diversitech WG840459 Multi-Horsepower (1/8, 1/6, 1/5, 1/3, 1/4) 208/230V 825 RPM Condenser Fan Motor

  • Manufacturers: DiversiTech
  • Brand Name: Wagner by Diversitech
  • Part#: 442862
  • MPN: WG840459
  • UPC: 09524716317
  • UOM: ea
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Company Availability: loading branchavailability

**Actual product may vary from image shown**


The Multi-Horsepower motors are specially designed to cover a range of applications. The condenser fan motors range from 1/2 to 1/5. 1/3 to 1/6 both at 1075 rpm. 1/3 to 1/6 at 825rpm. These motors feature reversing plugs, extended thru bolts 36 inch leads and are designed for 370 volt capacitors.

  • Standard 48 Frame Motor Casing Size
  • Standard Shaft Length, Diameter, and Flats
  • Electrically Reversible
  • Automatic Thermal Overload Protector
  • Class B Insulation
  • Continuous Air Over
  • Low Power Consumption
  • Quiet Operation
  • pdfData/Spec Sheet https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/Diveristech_442862.pdf
