Jomar Valve® 105-614G
  1. pin-int

Jomar Valve® 105-614G

3/4" In-Line Check Valve, Sweat, 150 lb, Brass Body, Jomar Valve® 105-614G S-521G

  • Manufacturers: Jomar Valve
  • Brand Name: Jomar Valve®
  • Part#: 260812
  • MPN: 105-614G
  • UPC: 662527305077
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Company Availability: loading
  • Next Day Delivery: loading
  • Available for pickup at : loading

Jomar Valve® In-Line Check Valve, Series: S-521G, 3/4 in Nominal Size, Solder, 150 lb, 250 deg F, Low Lead Compliance: Yes, 1.54 in Inlet to Outlet Length, Brass Body, PTFE Trim, Softgoods: PTFE® Seal, 2.06 in H

Body Material      :      Brass
Dimensions      :      2.06 in H
End Style      :      Solder
Inlet to Outlet Length      :      1.54 in
Low Lead Compliance      :      Yes
Nominal Size      :      3/4 in
Pressure Class      :      150 lb
Series      :      S-521G
Softgoods Material      :      PTFE Seal
Temperature Rating      :      250 deg F
Trim Material      :      PTFE
  • Can be installed in any position
  • Forged lead free brass body
  • Bubble tight teflon seal
  • Wetted surface contain less than 0.25 % lead content
  • 300 WOG
  • pdfCatalog https://assets.unilogcorp.com/2/ITEM/DOC/Jomar_Valve_400001_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/2/ITEM/DOC/Jomar_Valve_105613G_Specification_Sheet.pdf
