Bell & Gossett 110193LF

1/2" Union NPT/C, Lead Free Pressure Reducing Valve, 10 to 25 psig, 6-1/2gpm to 7 gpm, Brass

  • Manufacturers: Xylem
  • Brand Name: Bell & Gossett
  • Part#: 105020
  • MPN: 110193LF
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Company Availability: loading branchavailability

Bell & Gossett Pressure Reducing Valve, Model FB-38TU, 1/2 in Nominal Size, Union NPT/C, 10 to 25 psig, 225 deg F, 6-1/2 to 7 gpm, Media: Water, 4-31/32 in Inlet to Outlet Length, 3-11/16 in Top to Inlet Center, Brass Body, 4-13/16 in H

Body Material      :      Brass
Dimensions      :      4-13/16 in H
End Style      :      Union NPT/C
Flow Rate      :      6-1/2 to 7 gpm
Inlet to Outlet Length      :      4-31/32 in
Media      :      Water
Nominal Size      :      1/2 in
Pressure Rating      :      10 to 25 psig
Temperature Rating      :      225 deg F
Top to Inlet Center      :      3-11/16 in
