Apollo™ 94MBV02

1/4" 2-Piece Ball Valve, Instrumentation, MNPT x FNPT, Brass, Full Port, Apollo™ 94-MBV-02

  • Manufacturers: Apollo Conbraco
  • Brand Name: Apollo™
  • Part#: 338203
  • MPN: 94MBV02
  • UPC: 670750241154
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Company Availability: loading
  • Next Day Delivery: loading
  • Available for pickup at : loading

Apollo™ 2-Piece Ball Valve, Instrumentation, Series: 94MBV, 1/4 in Nominal, MNPT x FNPT, 600 psi Pressure Rating, -40 to 300 deg F Temperature, Full Port, Reversible Handle Actuator, Chrome Plated Brass Ball, 1.95 in Inlet to Outlet Length, 1.09 in Top to Inlet Center, Brass Body, Brass Stem Trim, Softgoods Material: TFE Seat/Fluorocarbon O-Ring, Domestic

Actuator Type      :      Reversible Handle
Ball Material      :      Chrome Plated Brass
Body Material      :      Brass
Domestic/Import      :      Domestic
End Style      :      MNPT x FNPT
Inlet to Outlet Length      :      1.95 in
Nominal Size      :      1/4 in
Port Type      :      Full
Pressure Rating      :      600 psi
Series      :      94MBV
Softgoods Material      :      TFE Seat/Fluorocarbon O-Ring
Temperature Rating      :      -40 to 300 deg F
Top to Inlet Center      :      1.09 in
Trim Material      :      Brass Stem
Type      :      Instrumentation
Warranty      :      5 Years
  • pdfCatalog https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/Apollo_77V-104-01_Catalog.pdf
  • pdfInstruction/Installation Sheet https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/Apollo_94MBV02_Installation_Instruction.pdf
  • pdfData/Spec Sheet https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/Apollo_94MBV02_Data_Sheet.pdf
  • linkVideo Link https://youtu.be/qy5qmtgTtPQ
