| Dimensions | : | 3.07 in L |
| Domestic/Import | : | Import |
| End Style | : | Press |
| Finish | : | Nickel Plated/Zinc Plated |
| Fitting/Connector Type | : | 90 deg Elbow |
| Material | : | Carbon Steel |
| Nominal Size | : | 1 in |
| Pressure Rating | : | 200 psi |
| Series | : | Model 5916 |
| Temperature Rating | : | 14 to 284 deg F |
MegaPress® FKM is a carbon steel, cold press system designed for use in chilled water, hydronic heating, compressed air, and fire sprinkler applications. MegaPress FKM fittings in sizes from 1/2 to 4 in are offered in configurations including: elbows, couplings, no-stop couplings, reducers, tees, reducing tees, adapters, unions, caps, and flanges.
MegaPress® Elbow, Series: Model 5916, Fitting/Connector Type: 90 deg Elbow, 1 in Nominal, Press, 200 psi, 14 to 284 deg F, Carbon Steel, Nickel Plated/Zinc Plated, 3.07 in L, Import
- Approved for more applications than any other carbon steel pipe press fitting system
- Corrosion resistant zinc nickel coating
- Nearly 150 engineered fitting configurations from 2-1/2 to 4 in
- Approved for underground applications, in accordance with code and local AHJ
- The same hanger and support requirements as threaded systems
- Viega Smart Connect® technology helps easily identify unpressed connections and provides installers added confidence in the integrity of connections
- 316 stainless steel valve/carbon steel press ends
- EPDM sealing element, PTFE stem seals
