GE Appliances NF96U090S4C

90K BTU 96% AFUE Single-Stage Upflow/Horizontal Flow Gas Furnace, 4-Ton Blower

  • Manufacturers: GE Appliances
  • Brand Name: GE Appliances
  • Part#: 518562
  • MPN: NF96U090S4C
  • UOM: EA
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Company Availability: loading
  • Next Day Delivery: loading
  • Available for pickup at : loading

GE Air & Water NF96U090S4C 90K BTU 96% AFUE Single-Stage Upflow/Horizontal Flow Gas Furnace, 4-Ton Blower, 33" x 21" x 28.5"

AFUE Rating      :      96%
Cabinet Width      :      21"
Cooling Capacity      :      4 Ton
Flow Direction      :      Upflow/Horizontal
Input      :      88,000 Btuh
Output      :      86,000 Btuh

  • Aluminized steel primary heat exchanger with crimped non-welded construction

  • AL 29-4C stainless steel secondary heat exchanger

  • Multi-speed high efficiency (constant torque) blower motor

  • Easily removable slide out blower design

  • Single-stage gas valve

  • Self-diagnostics saves last 10 fault codes regardless of power interruption

  • Designed certified for direct (2-pipe) and non-direct (1-pipe) applications

  • Left or right utility connections

  • Zero step horizontal conversion

  • Removable floor base (upflow / horizontal units) for bottom return air

  • pdfInstallation Manual https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/NF96US_Installation_Guide_11.14.22.pdf
  • pdfOwners Manual https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/NF96 Owners Manual.pdf
  • linkParts List https://www.ordergeapplianceparts.com/products/ge-appliances/hvac-gas-furnace/nf96u090s4c56?searchId=DhBlAAcD%2FgIBTmFtZf9ORjk2VTA5MFM0Q%2FwE%2Fg4BRGF0YXNldElkc%2F8z%2Ff0%3D
  • pdfSpecification Sheet https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/NF96 Spec Guide.pdf
  • pdfWarranty https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/NF96 Warranty.pdf
