Pro1® Non-Programmable Thermostat, 0.2 to 2 deg F Differential, Relay, 2 Switches, Terminal Designations: RH, RC, C, Y, W, G, B, O, 2 Stage, 24 VAC, 4 sq in LCD Display, Battery/Hardwired, Wall/Junction Box Mount, Black, 4.4 in H x 4.7 in W x 1.1 in D, Import
Color |
: |
Black |
Differential |
: |
0.2 to 2 deg F |
Dimensions |
: |
4.4 in H x 4.7 in W x 1.1 in D |
Display |
: |
4 sq in LCD |
Domestic/Import |
: |
Import |
Mounting Type |
: |
Wall/Junction Box |
Number of Stages |
: |
2 |
Number of Switches |
: |
2 |
Power Source |
: |
Battery/Hardwired |
Switch Action |
: |
Relay |
Terminal Designations |
: |
RH, RC, C, Y, W, G, B, O |
Voltage Rating |
: |
24 VAC |
Warranty |
: |
5 Years |
- 4 sq-inch display, blue back light glow in the dark light button, easy access battery compartment
- Electric or gas configurable, separate heating and cooling swing (cycle rate) adjustments, room temperature calibration adjustments
- 5 minute compressor delay protection (selectable on or off), simple private label badge system
- Easy wire color coded terminal blocks, universal sub-base, mounts on wall or junction box
- 32 to 105 deg F ambient operating temperature
- Temperature ranges 41 to 95 deg F display range of temperature, 44 to 90 deg F control range of temperature
- Humidity range - operating 90 percentage, non-condensing maximum
- +/- 1 deg F display accuracy, 1 A terminal, 1.5 a maximum all terminals combined load rating
- 18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire (common wire), battery power from 2 AA alkaline energizer batteries
-
Instruction/Installation Sheet
https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/Pro1_T701_Installation_Sheet.pdf
-
Data/Spec Sheet
https://www.capitolgroupinc.com//ASSETS/DOCUMENTS/ITEMS/EN/Pro1_T725_Specification_Sheet_1.pdf
